Gepon FTTH Catv mini Optical Receiver,Digital TV indoor Optical Receiver inch F Head With European Standard Power Supply

(0 Reviews)
In stock
Sold By:
The Server
LD Items
Price:
₱1,053.00
Quantity:
(9999 available)
Total Price:
Refund:
View Policy
Share:
Sold By
The Server
125 Durian Park Old Domestic Road 191 Zone 20 Pasay City
(0 customer reviews)
Visit Store
Top Selling Products
Description Reviews

Optical parameters: Received optical power: -18~+2 dBm Optical reflection loss: >45 dB Light receiving wavelength: 1100~1600 nm Optical connector type: FC/APC, SC/APC Link performance: Carrier-to-noise ratio (CN) ≥51 dB Carrier combination third order difference (C/CTB): ≥65dB Carrier combination second order difference (C/CSO): ≥63dB RF parameters Frequency range: 45~1100 MHz In-band flatness: dB ±0.5 (40~550~750/862/1100MHz) Output level: dbuv 0dB input (output 85dBm) -11dB input (output 68dBm) -18dB input (output 56dBm) Applicable to: GEPON network Supply voltage: 5V Power loss: ≤3W Output impedance: 75Ω MER value: Optical power input -15dbm> 33db -18bm ＞25db

There have been no reviews for this product yet.
