Tp-Link Archer TX20U Plus AX1800 Dual Antennas High Gain Wireless USB Adapter

Lightning-Fast WiFi 6 – Stream flawless video with 1800 Mbps wireless speeds (1201 Mbps on 5 GHz + 574 Mbps on 2.4 GHz)†

Flexible Dual Band – Ensure your PC has the best connection with 5 GHz and 2.4 GHz bands

Dual High-Gain Antennas – Connect from farther away with high-quality signals and transmissions

MU-MIMO – Maintain high download and upload speeds even when other devices are eating up your bandwidth△

OFDMA – Reduce your latency for impeccable conferencing and gameplay on crowded networks△

SuperSpeed USB 3.0 – Up to 10× faster transfer speeds than USB 2.0

Refined Security – Protect your personal data with the latest WPA3 encryption

HARDWARE FEATURES

LED Status

Dimensions 84 × 156.3 × 19.2 mm (3.3 × 6.2 × 0.76 in)

Antenna 2× High-Gain Dual-Band Antennas

WIRELESS FEATURES

Wireless Standards IEEE 802.11a/b/g/n/ac/ax

Signal Rate 5 GHz:

11ax: Up to 1201 Mbps(dynamic)

11ac: Up to 867 Mbps(dynamic)

11n: Up to 300 Mbps(dynamic)

11a: Up to 54 Mbps(dynamic)

2.4 GHz:

11ax: Up to 574 Mbps(dynamic)

11n: Up to 400 Mbps(dynamic)

11g: Up to 54 Mbps(dynamic)

11b: Up to 11 Mbps(dynamic)

Reception Sensitivity 5 GHz:

11ax HE80 MCS0: -90 dBm

11ax HE80 MCS11: -59 dBm

11a 54Mbps: -77 dBm

11ac VHT80 MCS0: -92dBm

11ac VHT80 MCS9: -64dBm

2.4 GHz:

11ax HE40 MCS0: -94 dBm

11ax HE40 MCS11: -66 dBm

11g 54Mbps: -79 dBm

11n HT40 MCS9: -74dBm

Transmit Power 5 GHz: 19dBm(FCC) /16dBm(CE) (EIRP)

2.4 GHz : 19dBm(FCC) / 14.5dBm(CE) (EIRP)

Wireless Modes Infrastructure mode

Wireless Security WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK

OTHERS

Certification FCC, CE, RoHS

Package Contents AX1800 Dual Antennas High Gain Wireless USB Adapter

Archer TX20U Plus

Quick Installation Guide

1-meter USB 3.0 Cable

System Requirements Supported operating systems only Windows 10, 11

Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
