FTTH Fiber Optic Tool Kit (Optical Power Meter, FC-6S Fiber Cleaver, Visual Fault Locator, Stripper)

1. OPTICAL POWER METER

FEATURES: Support linear indicators (mW) and non-linear indicators (dB) showing at the same time Support auto power-off and backlight ON/OFF Self-calibration by the user himself SC and FC Interface and ST interface (optional) Portable battery and computer power supply Battery working time (when unplugged) is up to 48 hours Have wavelength memory function and optical fiber work identification

SPECIFICATION: Wavelength range - 800〜1700 Connector - FC/SC/ST (ST optional) Type of Detector - InGaAs Power Measurement Range - -70〜+60 or 50〜+26 Uncertainty - +/-5% Standard Wavelength (nm) - 850/ 1300/ 1310/ 1490/ 1550/ 1625 Note: The optical power meter within the specified λ min - λmax range can work well with all indicators meeting requirements. Display Resolution - Linear indication (0.1%), Logarithmic indication (0.01dBm) Working Wavelength of Red light - 650 nm Working Temperature (°C) - -10〜+60 Storage Temperature (°C) - -25〜+70 Auto Power-off Time (min) - 10 Battery Working Time (h) - ≥ 48 Size (mm) - 190*100*48 or 165*75*28 Power - No. 5 battery *3 or rechargeable lithium battery Weight (g) - 400 2. FIBER CLEAVER SPECIFICATION: Fiber Cleaver Type - FC-6S Applicable Optical Fibers - Single-core silica Diameter of Optical Fiber coating - 0.25 & 0.9mm Diameter of Fiber Cladding - 125um Fiber Cutting Length - 9〜16mm (0.25mm) 10〜16mm (0.9mm) or more Size - 73mm (W) * 63mm (D) * 63mm (H) Weight - 385g A representative value of the cutting angle: ≤0.5° Blade Life: 48000 core wire 3. PEN-TYPE VISUAL FAULT LOCATOR SPECIFICATION: Model Number - TH15-5 Output Optical Power - >5mW Output Wavelength - 650mm Fiber Optic Adapter - Universal connector Working Temperature (°C) - 0〜 60 Storage Temperature (°C) - -20〜+70 Battery Type - 5 alkaline battery 2 Battery Life - >40h Size - 175mm * 26mm * 26mm Weight - 173g PACKAGE INCLUSIONS: 1 pc. Optical Power Meter 1 pc. Pen-type Visual Fault Locator 1 pc. FC-6S Fiber Cleaver 1 pc. CFS-2 Fiber Optic Cable Stripper 1 pc. Dropcore Fiber Optic Stripper 1 pc. 160ml alcohol bottle 1 pc. Black Carrying Bag 1 pc. Fixed length guiding rail 1 pc. Optical Power Meter Connector/Adapter 3 pcs. L-type Allen Keys 3 pcs. User's Manual
