90° Asymmetrical Beam Antenna - AH90-TP

Quick Specs:

• Brand: RF elements

• Model: AH90-TP

• Frequency Range: 5180 - 6000 MHz

• Gain: 16 dBi

• Antenna Connection: TwistPort™ - Quick Locking Waveguide Port

• TwistPort™ adapter included: NO

• Antenna Type: Horn

• Materials: UV Resistant ABS Plastic, Polycarbonate, HDPE, Aluminium, Stainless Steel

• Environmental: IP55

• Pole Mounting Diameter: 36-80 mm (we recommend as close to 80mm as possible)

• Temperature: -35°C to +55°C (-31°F to +131°F)

• Wind Survival: 160 km/hour

• Wind Loading: 76 N at 160 km/hour

• Azimuth Beam Width -3 dB: H 60° / V 60°

• Elevation Beam Width -3 dB: H 16° / V 16°

• Azimuth Beam Width -6 dB: H 90° / V 90°

• Elevation Beam Width -6 dB: H 25° / V 25°

• Beam Efficiency: 90% (defined up to first null)

• Front-to-Back Ratio: 30 dB

• Mechanical Adjustment: ± 25° Elevation, ± 20° Azimuth

‼ NOTE: This antenna is not the best for Point-to-Point (PTP) connections. It is made to be a station for Point-to-Multipoint (PTMP) connections.

For the best PTP connections, we recommend using RF elements UltraDish, Starter Dish, or UltraHorn.

-----

90° Asymmetrical Horn TP Antenna combines the best of both worlds - high gain of a traditional sector antenna and zero side lobes of a horn. Its radiation pattern is wide in azimuthal and narrow in elevation plane, greatly improving coverage planning options.

90° Asymmetrical Horn TP Antenna exceeds the traditional patch sector antenna thanks to high stability of gain and radiation pattern in the whole band of operation. Outstanding noise rejection and precision of radiation pattern favors 90° Asymmetrical Horn TP antenna for high-density AP clusters, in highly populated areas and dense co-location sites.

The HG3-TP-A90 features our revolutionary TwistPort™ connector - a patent-pending twist-and-lock waveguide port. TwistPort™ is virtually lossless and embodies a complete shift of paradigm in wireless network scalability and convenience of deployment.

90° Asymmetrical Horn TP Antenna supports a wide range of third party mainstream radios with our TPA TwistPort™ Adaptor.

-----

Package contents:

(1) AH90-TP Horn Antenna

(1) TwistPort RP-SMA Adapter

(1) Bracket Base

(1) Bracket Arm

(1) Bracket

(3) M6 x 20mm Screw

(2) M8 x 75mm Screw

(1) 2.9 x 16 mm Lock Screw
