Surecom SW-102 Meter 125-520 Mhz Digital VHF/UHF Power & SWR Meter SW102 For Two Way Radio

SURECOM SW-102 meter 125-520 Mhz Digital VHF/UHF Power & SWR Meter SW102 For Two Way Radio Main features: VSWR. Forward and reflected power direct readout, without any calibration. Maximum measurable power range up to 120W. low insertion loss (0.3 decibels or less) structure allows it to be permanently connected. Frequency counter function Visible operation: Frequency,Power,SWR,FW,RW **SL16 (N type) for measure handy radios** Specification Frequency test range: 125-520MHz Measurable power range: 1-120W test range of V.S.W.R: 1.00~19.9 Impedance: 50Ω Insertion Loss: < 0.15dB(VHF) , < 0.25dB(UHF) Temperature: 0 C~60 C Auto Power Off: 1-9 mins Interface: (in and out)N-J Interface Battery: 3.7V 600mAh Li-ion Battery Charger in 5V (micro usb) Volume: W76*H77*D35mm Weight: <220 grams (***Not work with digital radio***) How to use? Power ON/OFF: Press 2 second the [Red button] to power on & power off; Connect the Output of your transceiver to "TX" and Antenna or dummy Load to "ANT". Proper adaptor/cable is required if your device has different type of connectors. (***must use dummy load to avoid burn tester & to get accurate result when test power) Function menu display: 1) Adj. RF Forward % 2) Adj. RF Reward % 3) Adj. frequency counter time base. 4) Adj. RF Power % 5) Adj LCD dim of light 6)Adj. power off time 7)Adj. Power test mode [0 for 1-10W hand held radio , 5 for Mobile Radio 10-100W] Function Memory/ SAVE: 1. Press MENU [Blue button] 2. Press F1 [Red button] [Select 1-6 Function] 3. Press Blue button [- ], Yellow button [+] 4. Press the Red button for 2 seconds 5. Press the Blue button to SAVE and Exit MENU SETTING 1: RF Level of" Forward ": [-99 to +99] % 2: RF Level of "Reverse": [-99 to +99] % 3: Freq.counter"Time Base: [-99 to +99]% 4: Fine tune RF "Power Watt Level": [-99 to +99] % 5: LCD DIM [LCD Backlight Time]: "0" is ON, "1-9" mins 6: POWER OFF: "0" is ON, "1-9" mins Notice :SW-102 is not for DMR system
