Bosch Spark Plug
YR7DC
Bosch Part No. 0 242 135 512
Made in China
Hex Spanner Size: 5/8" (16mm)
Thread Size: 12mm
Thread Length: 19mm
Thread Pitch: 1.25mm
Spark Position: 3mm
Factory Gap: 0.9mm
Gasket Type: Gasket Seat
Tip Configuration: Single Electrode
Tightening Torque: 23nm
Tightening Angle: 90 degrees
Bosch Model Number Decoding (YR7DC):
"Y" - 12mm x 1.25mm, 16mm (Thread Size x Thread Pitch, Hex Spanner Size)
"R" - With interference suppression resistor
"7" - Bosch Spark Plug Heat Range
"D" - 19mm (Thread Length)
"C" - Copper Electrode
Cross Reference:
Bosch YR7DC+ (Super Plus)
Bosch YR7DI30 (Iridium)
NGK DCPR7E / DCPR7EA-9
NGK DCPR7EGP (Platinum)
Champion OE196
Nippondenso XU22EPRU / XU22PR9
Applications:
Suzuki F6A 0.6L Engine (12 Valve, Multicab)
Suzuki K6A 0.6L Engine (Multicab, 12 Valve "Short Thread")
Suzuki F8D 0.8L Engine (Alto 800)
Suzuki K10B 1.0L Engine (Celerio)
Suzuki K12B / K12M 1.2L Engine (Swift)
Suzuki K14B 1.4L Engine (Ciaz, Ertiga, Swift)
Chevrolet Sail 1.3/1.5 (from 2016)
Chevrolet Spark 1.0 (B10D1 Engine, from mid-2011)
Chevrolet Spin 1.5 LTZ (from 2012)
Toyota Avanza (1.3L K3-VE, 1.5L 3SZ-VE Engines, 2006-2015)
***Please cross reference with your current spark plugs***
***Each item is for One (1) Spark Plug***
