1.Applied to indoor coverage system, it can cover the whole band of 806-960MHz and 1710-2700MHz
2.Low intermodulation, up to -160dBc (@2×43dBm)
3.Ultra-wideband, covering 806~960MHz and 1710~2700MHzNovel style, small size, beautiful appearance
4.Easy to install
5.Meet RoHS
6.It’s a real bargain ,Hot, Good quality, Buy it at ease
Attention:
This is an panel antenna only. It doesn't work alone.
You need a Signal Booster/Repeater to work with this.
Electrical Specifications :
Frequency Range(Mhz) 880~960 1710~1850 1885~1915 2010~2025 2300~2400 2400~2483.5 2575-2635
Gain(dBi) 》6.5 》7.5 》7.5 》7.5 》8 》8 》8
VSWR ≤1.5
Horizontal Beam Width(°) 90±10 75±10 75±10 75±10 75±10 75±10 75±10
Vetical Beam Width(°) 85 65 65 65 65 60 55
Front to Back Ratio(dB) 》12 》15 》15 》15 》15 》15 》15
Polarrization Vertical
Intermodulation IM3(dBM) ≤-85 ≤-85 / / / / /
Input Maximum CW Power 》50W
Impedance 50Ω
Mechanical Specifications:
Antenna Type Single-polarized directional antenna
Applicable environment Indoor/Outdoor
Input Connector N-Female
Dimensions of antenna 169X149X47mm
Weight of antenna 0.3Kg
Gross weight 0.364Kg
Cable Type RG58
Temperature range -30℃~+45℃
Radonme material ABS
Package Include :
1 X Panel Antenna
1 X Baffle
2 X Plastic Wall Plug
2 X Self-tapping Screws
