Version Tx Rx (Working range)
144–148 136–174*1
144–146 136–174*2
Guaranteed range *1 144–148MHz, *2 144–146MHz
Mode FM
No. of memory Ch. 107 (incl. 6 scan edges and 1 call)
Operating Temp. range:–10°C to +60°C ; +14°F to +140°F
Frequency stability:±2.5ppm (–10°C to +60°C)
Power supply requirement:BP-226/BP-227 or 11.0V ± 15% (External DC in)
Current drain:(at 7.2V DC)
Tx High (7W):2.6A
Rx Max. audio:250mA
Stand-by:80mA
Power save:30mA
Antenna impedance:50Ω (BNC)
Dimensions (W×H×D)(Projections not included):
56 × 110 × 34.4 mm;
