NGK G-Power Series offers the performance and durability of platinum at a competitive price. Fine wire platinum tipped center electrode reduces required voltage for better starts, superior acceleration and increased fuel economy.
*Trapezoid cut ground electrode reduces quenching
*Trivalent metal plating provides superior anti-corrosion and anti-seizing properties
*Corrugated ribs prevent flashover
*Pure alumina silicate ceramic insulator, provides superior strength and better heat transfer
*Copper core aids in heat removal
*Triple seals prevent leakage
-Thread Diameter
12mm
-Thread Pitch
1.25mm
-Seat Type
Gasket
-Reach
26.5mm (1.04")
-Hex Size
5/8" (16mm)
-Terminal Type
Solid
-Gap
.039" (1.0mm)
Material
Platinum
-Type
Fine Wire
-Size
0.6mm
-Projection
Projected
*Ground Electrode
-Material
Nickel
-Type
Standard
-Shape
Trapezoid
*Specifications
-Resistor
Yes
-Heat Range 6
*Features
Special Resistor
-Torque Specs
Cast Iron: 10.8-18 lb. ft. Aluminum: 10.8-14.5 lb. ft.
