Measurable power range: 0.1-100W
Max. power: 100W Accuracy: mean + / - 5%
Not for the DMR digital radio.
MAX. Power in: 100W
V.S.W.R: 1.00~19.99
Frequency Range: COVER - 125MHz~525MHz
Insertion Loss: < 0.15dB(VHF) , < 0.25dB(UHF)
Temperature: 0℃~70℃
Battery Built-in: Li-ion Battery
Size:(WHIT OUT SMA): 25*25*60 (mm)
Power in: 5V (micro usb)
Interface (in and out ): SMA female
Impedance: 50Ω
Weight: 160g
Features function
Push red button and hold 3 sec.to"" Power on "" and ""SWR ""mode ""
Push red button -"" Power Meter ""mode
Push red button -"" SWR ""mode
Push red button and HOLD -"" POWER OFF
