Alinco DJ-A10 Vhf Portable Radio

Features ●128 channels to program operating parameters via PC utility software ●Channel, Name tag and VFO (Frequency) display modes selectable ●Comes with a rechargeable Li-Ion pack, desktop quick-charger and high-performance whip antenna ●Ergonomically designed compact body 59.0W x 98.0H x 35.0D mm or 2.32W x 3.86H x 1.38D inches (w/o projections, approx.), weighs approx.227g or 8.01oz inclusive of battery pack and antenna ●3 types of Scan functions (VFO/Memory channels/Priority), 50 CTCSS, 116 DCS and 4 Tone-burst tones ●Backlit, Dot Matrix LCD screen with alphanumeric name tag ●Microphone and speaker ports ●Includes FM radio receiver, Internal VOX, Voiceprompt in English, Remote-Kill/Stun/Waken, Analog scrambling, Voice Compander, Narrow FM, Repeater-reverse, Auto-Power-OFF, Busy-ChannelLockout, Time-Out-Timer and more and more at No extra cost! Specifications ●Frequency coverage ： [TX/RX］ 136.000-173.995MHz [RX only] 76-108MHz ●Mode ： F3E(16K0F3E / 11K0F3E / RX only WFM) ●Programmable channels ： 128 channels ●Frequency stability ： ±2.5ppm ●Power supply requirement ： 7.4V DC±20% (negative ground) ●Current drain (Approx.) ： 1400mA TX / 300mA receive at Max audio output / 70 mA squelched ●Usable temperature range ： －20～ +55℃(-4～131°F) ●Dimensions　(Projections not included/approx.) ： 59.0W×98.0H×35.0D mm or 2.32W×3.86H×1.38D inches ●Weight : approx.227g or 8.01oz inclusive of battery pack and antenna Transmitter (ETSI EN300 086 compliant) ●Output power ： Approx.5 / 2 / 0.5W ●Modulation system ： Variable reactance FM ●Spurious emissions ： Less than －36dB ●Max. frequency deviation ： ±5kHz / ±2.5kHz Receiver (ETSI EN300 086 compliant) ●Receive system ： Double conversion superheterodyne ●Intermediate frequencies ： 38.85MHZ ●Sensitivity(12dB SINAD Wide/Narrow) ： －12dBμ or better 　(0.25μV/0.35μV) or better ●Selectivity ： －6dB : －6dB : Wide 12kHz /Narrow 10kHz or more 　 －60dB :Wide 30kHz / Narrow 24kHz or less ●Audio output power ： 1000mW(8Ω / Max)
