Fbt Fiber Splitter 1*2 SC/UPC Fiber Optic Splitter Beam Splitter 2 Meter
-
Fiber Optic Tools Kit & Equipment
₱3,853.00
PRODUCT DESCRIPTION
PLC splitter is based on planar Lightwave circuit technology and precision aligning process. It can divide a single/dual optical input(s) into multiple optical outputs uniformly and is denoted 1xN or 2xN. PLC splitter is applied in FTTX deployments, PON networks, CATV links and optical signal distribution currently.
FEATURES
Uniform power splitting with good transmission stability
Low insertion loss and low dependent loss
Excellent Environmental Stability and Widely Used
Good Repeatability and Interchangeability
High Reliability and High Return Loss
Low Polarization Dependent Loss Excellent Mechanical, Small Size
Good temperature stability
PRODUCT SPECIFICATIONS
Product Model: FBT-1X2 SC/UPC
Length: 2 meter
Size: 60mm X 20mm X 10mm
Weight: 40 grams
Executive Standard: Q/ WGTXFBT088-2019
Test wavelength: 1310 nm
Working wavelength: 1260nm~1650nm
Interface model: SC/UPC
Insertion loss (dB) (P/S level): ≤ 3.7dB
Loss uniformity (dB): 0.4
Return loss (dB) (P/S level): ≥ 55dB
Polarization dependent loss (dB): 0.2
Directionality (dB): 55
Wavelength dependent loss (dB): 0.3
Temperature stability (dB): 0.4
APPLICATIONS
Used in FTTH, FTTB, and FTTX Systems
Used in LAN, WAN and Metro Networks
Used in Analog/Digital Passive Optical Networks
Cable TV Networks
Used in testing Equipment and other applications in fiber optic systems
PACKAGE INCLUSIONS
1 pc.1x2 PLC Optical Fiber Splitter
