Features:
• 4.95-7.125GHz Frequency
• 25dBi High Gain
• MIMO
• Dual Slant (V/H or ±45°)
• 1 feet Dish
Application:
Applications
• 4.9/5.1/5.3/5.4/5.8/6.4/7.125 GHz ISM and UNII Band
• MIMO and 802.11n Applications
• WiMAX Applications
• Long Distance Backhaul and Point to Point Data Links
Technical Specifications:
Electrical
Model : ANT4971D25P-MIMO
Frequency Range : 4.95-5.1GHz 5.1-5.9GHz 5.9-7.125GHz
Gain( dBi) : 24dBi , 24.5dBi , 25dBi
VSWR : <2.5 , <2.0 , <2.0
Polarization
Dual Slant (V/H or ±45°)
Isolation : >30dB
Front to Back Ratio : >30dB
Horizontal Beam width : 9°
Vertical Beam width : 9°
Maximum Power Per Port " 50W
Impedance : 50Ω
Lighting protection : DC Ground
Mechanical
Connector : 2 * RPSMA
Antenna Size : φ0.4m
Antenna Weight : 2.5kg
Antenna color : white
Dish material : aluminum
Diameter of the Pole : Φ30 to φ80 mm
Operational Temperature : -40°C to +70°C (-32°F to +158°F)
