Features
• 698-3800MHz Frequency • 20dBi High Gain • MIMO • Dual Slant (±45°)
Application
• Works on any 3G / 4G / LTE / CBRS / 5G cellular network such as Verizon, AT&T, Sprint, T-Mobile and more • Dual Antenna MIMO Design Improves Performance
Technical Specifications:
Electrical
Model : ANT0638D20PG-XP
Frequency Range
698-960MHz
1710-2690MHz
3300-3800MHz
Gain
9±2dBi
18±2dBi
20±2dBi
VSWR
<2.5
<2.0
<2.0
Polarization
Dual Slant (±45°)
Isolation
>15dB
>15dB
>15dB
Front to Back Ratio
>8dB
>15dB
>20dB
Horizontal Beam width
40±10°
25±10°
20±10°
Vertical Beam width
40±10°
25±10°
20±10°
Maximum Power Per Port
50W
Impedance
50Ω
Lighting protection
DC Ground
Mechanical
Connector
2 * N/RPSMA/SMA
Antenna Size
φ0.6 m
Antenna Weight : 2kg
Antenna color : white
Diameter of the Pole
Φ30mm to φ50mm
Mechanical Tilt : ± 25°
Operational Temperature :-40°C to +70°C (-32°F to +158°F)
