Color Graphic Antenna Analyzer
Item Specifics:
- Antenna analyzers designed for testing, checking, tuning or repairing antennas and antenna feed lines.
- Mainly, these are S.W.R. (Standing Wave Ratio) and impedance measurement instruments (vector impedance analyzers).
- Easy-to use measurement modes. Make attractive for professionals and hobbyists.
- It is quite important that graphical display of various parameters over a wide frequency range is a key feature of these analyzers which significantly reduces the time required to adjust an antenna.
Frequency Range: 27MHz - 3000MHz
Size: 70 x 90 x 25mm
(1mm=0.393Inches)
Main Features:
■ LCD screen,High-lumen LCD brightness, easy to read in direct sunlight.
■ Heavy duty Aluminum enclosure,strong anti-interference ability.
■ Very compact and convenient for field use.
■ Built-in rechargeable Li-ion battery.
■ Full Band control (No need select Band).
■ Easy setup, only four control buttons with convenient on-screen soft menus.
■ Constant Battery Status Indicator and Auto Shut-off.
■ Built-in timer shows elapsed time when unit is turned on.
Power Management
Power Source: Built-in 3.7V, Li-ion Battery
Charge Controller: Smart charger, LED charging-status indicator
Voltage Monitor: On-screen DVM, plus battery condition icon
Charger Source: Any USB port, analyzer accepts Micro-USB plug
Power Savers: Auto-off timer, Auto Run/Stop RF generator control Interface
Battery Charge Connector: Micro-USB
Function Keys: 4 botton, with on-screen (soft-menu) identifiers
Tuning: Rotary encoder with press-in tuning-step selection
Package Included:
1 x Frequency Counter Meter
1 x Charger(US Plug)
1 x English Manual
