Lanbowan 4.9-6.5GHz 19dBi Horn Antenna I PTP Antenna (ANT4965D19P-MIMO) [Similar to Ubiquiti Horn‑5‑30 I Horn5-30 I Horn 5-30] I 5Ghz Antenna I 6Ghz Antenna I For Ubiquiti / Ubnt / Mimosa Networks / Cambium / Mikrotik / Radwin I Ubiquity
Features:
4.9-6.5 Ghz Frequency
19dbi High Gain
Mimo
Dual Linear (V/H or +-45
Applications:
4.9/5.1 3/5.4/5.8/6.4 Ghz ISM and UNII Band
Mimo and 802.11n Applications
Elevation Beam Width -6 dB:V30° / H30°Long Distance Backhaul and Point to Point Data Links
SPECIFICATIONS:
Electrical
Model:ANT4965D19P-MIMO
Frequency Range:4.9-5.1GHz 5.1-5.9GHz 5.9-6.5GHz
Gain( dBi):18dBi 19dBi 19.5dBi
VSWR:<2.0 <2.0 <2.0
Polarization:Dual-Linear (V/H or ±45°)
Isolation:>30dB
Front to Back Ratio:40dB
Azimuth Beam Width -3 dB: V20° / H20°
Elevation Beam Width -3 dB: V20° / H20°
Azimuth Beam Width -6 dB: V30° / H30°
MECHANICAL
Connector:2* N Female or 2*RPSMA
Antenna Size:279x208x286mm
Antenna Weight:1.5kg
Antenna color:white
Horn material:aluminum
Diameter of the Pole:Φ30mm to φ80mm
Mechanical Tilt:± 25°
Operational Temperature:-40°C to +70°C (-32°F to +158°F)
