BAOFENG BF-12P Commercial FM Radio Receiver Black Digital Walkie Talkie Dual Band 136-174 / 400-480MHz Two Way Radio UHF VHF (Black)
MODEL: BAOFENG BF-12P
100% brand new and high quality
Dual-band handheld transceiver with display function menu on the display "LCD".
DTMF Code
Lithium-ion battery with high capacity
Commercial FM radio receiver (65 MHz ~ 108MHz)
Incorporates 105 codes “DCS” and 50 privacy codes “CTCSS” programmable
Built-in VOX Function (voice operated transmission)
Alarm Function
High &Low Power Switchover
Battery Savin
Wide/Narrow Band Selection
Display illumination and programmable keyboard
Time-out Timer (TOT)
Voice Prompt
ANI Code
Programmable by PC
PTT-ID
AUTO Keypad Lock
Function “beep” on the keyboard
Built-in RX CTCSS/DCS scan
Low Battery Warning
U/V Cross Band Dual Watch
LCD Function
Built-in LED flashlight
Level Threshold “Squelch” adjustable from 0~9
Cross band reception
Tone end of transmission
Built-in key lock
Frequency Range65MHz-108MHz(Only commercial FM radio reception)
VHF: 136-174MHz(Rx/Tx)
UHF:400-480MHz(Rx/Tx)
Memory ChannelUp to 128 channels
Frequency stability2.5ppm
Frequency step2.5KHz/5KHz/6.25KHz/10KHz/12.5KHz/25KHz
Rated Voltage7.4 V
Battery Capacity1800mAh
Work Temperature-20to +60
Antenna Impedance50 Ω
Consumption in standby≤ 75mA
Consumption in reception380mA
Consumption in transmission≤1.4A
Mode of Operation Simplex or semi-duplex
Duty cycle03/03/54 min. (Rx/Tx/Standby)
Dimension110x58x32mm
Weight130g (approximate)
RF power4W/1W
Type of modulation FM
Emission class16kΦF3E / 11kΦF3E (W/N)
Maximum deviation≤ ±5kHz / ≤ ±2.5kHz (W/N)
Spurious emissions<-60dB
Sensitivity0.2 µ V (at 12dB SINAD)
Inter modulation60dB
Audio Output1000mW
Adjacent channel selectivity65/60dB
