Mimosa 5ghz 1gbps Capable Ptp Backhaul Connectorized B5c I Similar To Ubiquiti Af-5xhd Infobahn

SPECIFICATIONS: Performance Max Throughput Up to 1.5 Gbps IP aggregate UL/DL (1.7 Gbps PHY) Low Latency < 1 ms in Auto Mode Wireless Protocols TDMA, TDMA-FD Radio MIMO & Modulation 4x4:4 MIMO OFDM up to 256QAM Bandwidth* Single or Dual 20/40/80 MHz channels Frequency Range 4900-6200 MHz restricted by country of operation (*new* US/FCC 5600-5650 support) Max Output Power 30 dBm (2-stream), 27 dBm (4-stream) Sensitivity ( MCS 0 ) -87 dBm @ 80 MHz -90 dBm @ 40 MHz -93 dBm @ 20 MHz Power Max Power Consumption 20W System Power Method 48 V DC 802.3 at compliant power injectors System Lightning & ESD Protection 6 kV PoE Power Supply Passive POE compliant, 48-56 V Power over Ethernet supply with IEC61000-4-5 surge protection Physical Dimensions Height: 267 mm (10.5") Width: 158 mm (6.2") Depth: 74 mm (3") Weight 1.6 kg (3.5 lbs) Enclosure Characteristics Outdoor UV stabilized plastic Aluminum mounting panel Wind Survivability 200 km/h (125 mph) Wind Loading 9.89 Kg @ 160 km/h (21.8 lbs @ 100 mph) Mounting Dual standard pole straps for 30 mm (1.18") to 90 mm (3.54") OD pipes Connector Type Female Type N (x2), intended for use with dual polarization antenna * 4.9 GHz uses 20 MHz channel widths (US only, regulations vary by region) Environmental Outdoor Ingress Protection Rating IP67 Operating Temperature -40°C to +55°C (-40°F to 131°F) Operating Humidity 5 to 100% condensing Operating Altitude 4420 m (14500') maximum Shock & Vibration ETS 300-019-2-4 class 4M5 Features Gigabit Ethernet 10/100/1000-BASE-T Dual Link Operation 2 independent dual-stream radios operating on non-contiguous frequencies Automatic load balancing of traffic across 4 total MIMO streams with individual stream encoding up to 256 QAM Management Services Mimosa cloud monitoring and management SNMPv2 & Syslog legacy monitoring HTTPS HTML 5 based Web UI 2.4 GHz 802.11b/g/n radio for local management access Smart Antenna Alignment Hands-free dedicated 2.4 GHz Wi-Fi management radio alignment tool‡ Smart Spectrum Management Active scan monitors/logs ongoing RF interference across channels (no service impact) Dynamic auto-optimization of channel and bandwidth use Security 128-bit AES PSK with hardware acceleration QoS Supports 4 pre-configured QoS levels GPS Location GNSS-1 (GPS + GLONASS) Colocation Synchronization 1PPS GPS TX/RX synchronization for collocated co-channel radios Adjustable up/downstream bandwidth ratio Regulatory + Compliance Approvals FCC Part 15.407 and Part 90Y, IC RSS210 and RSS111, CE, ETSI 301 893/302 502 Other National Regulations RoHS Compliance Yes Safety UL/EC/EN/ 60950-1 + CSA-22.2
