FEATURES
Easily installed. Quick assembly SC connector can provide quick and easy termination of fibers in the field.
It allows the installer to terminate and make connection in minutes at equipment and fiber patch panels.
This connector system removes any requirement for epoxy, adhesive or costly curing ovens, with features of installation quality, high success rate and high reliability.
Carrier-grade. Using advanced three-ring ceramic ferrule, low insertion loss
Installation and maintenance can be completed using common tools for optical fiber construction
Metal V-shape cavity work well in high and low temperature
Reliable and superior optical performance
Insertion Loss: <0.3dB
Return Loss: ≤ 55dB
PRODUCT SPECIFICATIONS
Connector Type: SC-APC
Brand Name: OEM
Cable Scope: 3.0mm x 2.0 mm and 1.6mm x 2.0mm Bow-type Drop Cable
Size: 51mm x 9mm x 7.55mm
Coating Diameter: 250μm
Installation Operating Time: about 15 seconds (excluding fiber pre-setting)
Fiber Mode SM/MM
Grinding end-face: APC
Insertion Loss: ≤ 0.3dB (1310nm and 1550nm)
Return Loss: ≤ 55dB
Success Rate: >98%
Reusable Times: >5 times
Tension Test: ≥100N
Tighten Strength of Naked Fiber: >5N
Tensile Strength: >30N
On-line Tensile Strength Test (20 N): IL ≤ 0.3dB
Mechanical Durability Test (500 times): IL ≤ 0.3dB
Drop Test: IL ≤ 0.3dB
Operating Temperature: -40℃~+85℃
APPLICATION
A popular solution for optical wiring inside buildings and floors for LAN, CCTV, and FTTH applications.
Used to open the FTTH fiber terminal end.
Use in the box cabinet, such as wiring into the box.
Use for fiber maintenance.
Use for LAN, WAN, and data and video transmission.
Use for the construction of the fiber end user access and maintenance.
Use for optical fiber access of mobile base station.
PACKAGE INCLUSIONS
10 pcs. SC-APC Fast Connector
1 pc. Fixed length guiding rail (included for every order of 5 packs Fast Connector only)
